Soulution / Serie 5 – 520 PRE-AMP

Visiter le site de la marque

Dynamics. Resolution. Control. Musicality. All as close to perfection as possible. It’s what characterizes a top class preamplifier. The Soulution 520 meets these challenges and more. With four line inputs and a high quality phono stage built in, the Soulution 520 is perfectly equipped for all audiophile requirements.

Specifications:

Nominal voltage
Model 220 – 240 V / 50 – 60 Hz		220 – 240	V
Model 100 – 120 V / 50 – 60 Hz		100 – 120	V

Consumption
OFF (standby)		<0.5	W
Operation		100	W

Input (IN 1 … IN 5)
Impedance	balanced (IN 1… IN2	3	kΩ
	unbalanced (IN 3…IN4)	3	kΩ
	Phono (IN 5)	adjust..


Output
Gain	balanced	-83…+16	dB
	unbalanced	-89…+10	dB
Frequency response		DC-800	kHz
THD+N		<0.001	%
Signal-to-Noise Ratio		>120	dB
Crosstalk		<120	dB
Impedance	balanced	10	Ω
	unbalanced	10	Ω

LINK-System		+12	V
